WIWA INJECT 2K 230
- Large conveying volume
- Long lengths of the hose can be adapted
- Quick start-up, easy maintenance, easy and quick cleaning
Description
Our 2K piston pump with exchangeable mixing ratio.
Due to the positive control and always the same switching points, you get the perfect dosing with the WIWA INJECT 2K 230. It is strongly characterized by its high delivery rate. In addition to the standard mixing ratio of 1:1, over 100 other mixing ratios are possible by replacing the material pumps. Aqueous and low-viscosity as well as high-viscosity materials are no problem.
Suitable accessories
Selection of project references
Technical Data
Model
|
INJECT 2K 230030 |
| Pressure ratio | 30:1 |
| Output per cycle | 194 ccm |
| Max. inbound air pressure | 8 bar |
| Max. operating pressure | 240 bar |
| Order numbers | |
| N/G | 0669709 |
| N/F | 0669708 |
| RS/F | 0669711 |
| RS/G | 0669712 |
|
Model
|
INJECT 2K 230032 |
| Pressure ratio | 32:1 |
| Output per cycle | 180 ccm |
| Max. inbound air pressure | 8 bar |
| Max. operating pressure | 256 bar |
| Order number | |
| N/G | 0669710 |
|
Model
|
INJECT 2K 230040 |
| Pressure ratio | 40:1 |
| Output per cycle | 144 ccm |
| Max. inbound air pressure | 8 bar |
| Max. operating pressure | 320 bar |
| Order number | |
| RS/G | 0669713 |
B - On container, D - on tripod, F - on chassis, G - on rack, GZ - On Rack with feed funnel, W - on wall mount,
ASL - suction tube, DAS - Direct suction
Fields Of Application
![[Translate to Englisch:]](/fileadmin/Produkte/Einsatzgebiete/Injektion/Bergbau_grau1.svg "[Translate to Englisch:]")
Mining
![[Translate to Englisch:]](/fileadmin/Produkte/Einsatzgebiete/Injektion/Bausanierung_grau1.svg "[Translate to Englisch:]")
Building renovation
![[Translate to Englisch:]](/fileadmin/Produkte/Einsatzgebiete/Injektion/Rohre_Piplines_grau1.svg "[Translate to Englisch:]")
Pipes and pipelines
![[Translate to Englisch:]](/fileadmin/Produkte/Einsatzgebiete/Injektion/Bauten_Korrosionsschutz_grau1.svg "[Translate to Englisch:]")
Building and corrosion protection
![[Translate to Englisch:]](/fileadmin/Produkte/Einsatzgebiete/Injektion/Tunnel_grau1.svg "[Translate to Englisch:]")
Tunnels
![[Translate to Englisch:]](/fileadmin/Produkte/Einsatzgebiete/Injektion/Hoch_Tiefbau_grau1.svg "[Translate to Englisch:]")
Building and civil engineering
Materials
- 2K injection resins
- Polyurethane resins
- Silicate resins
- Polyurethane injection foam resins
- PUR
- Polyurethane Combi Resins
- Polyurethane injection resins
- PUR Casting foam resins
- acid curing foams
- Acylatgele
Our 2K piston pump with exchangeable mixing ratio.
Due to the positive control and always the same switching points, you get the perfect dosing with the WIWA INJECT 2K 230. It is strongly characterized by its high delivery rate. In addition to the standard mixing ratio of 1:1, over 100 other mixing ratios are possible by replacing the material pumps. Aqueous and low-viscosity as well as high-viscosity materials are no problem.
Suitable accessories
Selection of project references
|
Model
|
INJECT 2K 230030 |
| Pressure ratio | 30:1 |
| Output per cycle | 194 ccm |
| Max. inbound air pressure | 8 bar |
| Max. operating pressure | 240 bar |
| Order numbers | |
| N/G | 0669709 |
| N/F | 0669708 |
| RS/F | 0669711 |
| RS/G | 0669712 |
|
Model
|
INJECT 2K 230032 |
| Pressure ratio | 32:1 |
| Output per cycle | 180 ccm |
| Max. inbound air pressure | 8 bar |
| Max. operating pressure | 256 bar |
| Order number | |
| N/G | 0669710 |
|
Model
|
INJECT 2K 230040 |
| Pressure ratio | 40:1 |
| Output per cycle | 144 ccm |
| Max. inbound air pressure | 8 bar |
| Max. operating pressure | 320 bar |
| Order number | |
| RS/G | 0669713 |
B - On container, D - on tripod, F - on chassis, G - on rack, GZ - On Rack with feed funnel, W - on wall mount,
ASL - suction tube, DAS - Direct suction
Fields Of Application
Mining
Building renovation
Pipes and pipelines
Building and corrosion protection
Tunnels
Building and civil engineering
Materials
- 2K injection resins
- Polyurethane resins
- Silicate resins
- Polyurethane injection foam resins
- PUR
- Polyurethane Combi Resins
- Polyurethane injection resins
- PUR Casting foam resins
- acid curing foams
- Acylatgele
